| Printhead configuration | PrecisionCore MicroTFP printhead 9,600 nozzles |
| Maximum print speed | 119.4 m2/h |
| Minimum ink droplet volume | 4.2 pl |
| Maximum print resolution | 1200x1200 dpi |
| Media width | 300 to 1,625.6 mm (64") |
| Maximum media thickness | less than 1 mm |
| Roll outer diameter | Up to 250 mm |
| Reel outer diameter | Up to 250 mm |
| Roll weight | Up to 45 kg |
| ink | Ultra Chrome GS3 ink |
| Number of ink | 6 colours (C, M, Y, K, Lc, Lm) |
| Ink capacity | 800ml / 1500 ml |
| Print speed (default) | PVC 14.0 m2/hr (10 pass) Film 7.2 m2/hr (17 pass) Banner 20.1 m2/hr (6 pass) |
| Software | Epson Edge Pro |
| Connectivity | SuperSpeed USB*1 100BASE-TX/1000BASE-T (Recommended) |
| Control panel | 10.9 cm (4.3") Optical Touch Colour LCD |
| Dimensions | W: 2,620 mm H: 1,021 mm D: 925 mm |
| Weight (without ink cartridge) | 342 kg |
| Voltage | AC 100-120 V or 200-240 V 50/60 Hz |
| Warranty | 2-3 year onsite |
| Auto media setup | Yes |
| Main unit | SC-S9130 C11CL38403 |
